स्टकमा उपलब्ध लोकप्रिय उत्पादन
LPF-60-42
LPF-60-42 MEANWELL AC-DC Single output LED driver Mix mode (CV+CC), Output 42VDC / 1.43A, cable output
$0.00USD
3969 स्टकमा
मुख्य विशिष्टताहरू
नाम:LPF-60-42
राज्य:Do not Use for New Designs
ढाँचा:Box
शृङ्खला:LPF-60
आपूर्तिकर्ता जानकारी
MEANWELL
उत्पादहरू: 6448
सामान्यतया २-३ कार्यदिवसभित्र पठाइन्छ
गुणस्तर ग्यारेन्टी
छिटो शिपिङ
प्राविधिक सहयोग
प्राविधिक विशिष्टताहरू
| प्यारामीटर | मूल्य |
|---|---|
| नाम | LPF-60-42 |
| राज्य | Do not Use for New Designs |
| ढाँचा | Box |
| शृङ्खला | LPF-60 |
| अनुमोदनहरू | CCC, CE, ENEC, PSE, UL |
| पावर (W) | 60,00 |
| उपढाँचा | IP67 |
| चौडाइ (मिमी) | 43.00 |
| उचाइ (मिमी) | 32.00 |
| एसी इनपुट अधिकतम | 305,00 |
| न्यूनतम एसी इनपुट | 90,00 |
| अनुप्रयोगहरू | Lighting |
| निर्माता | MEAN WELL |
| उत्पादनको प्रकार | LED Driver |
| आइसोलेसन (V) | 3.750,00 |
| अधिकतम शक्ति (W) | Sixty |
| इनपुट कनेक्टर | Cable |
| इनपुट फ्रिक्वेन्सी | 50 Hz, 60 Hz |
| लामो/पृष्ठभूमि | 162.50 |
| लामो विवरण | LED driver.Specially designed for powering LEDs directly in a steady stream.Format in box waterproof plasticIP67.Input range90-305Vca47-63Hz.Output in constant current1430mA.Range of output voltage with current mode constant25,2 to 42Vccaccording to demand load.Power:60W.Efficiency typical:Ninety%.Input class II without grounding.Factor corrector, power>0.95to 230vac at full load.Operating temperature range of caseTcfrom-40ºCup+70ºC.Dimensions (Length x Width x Height):162,5 x 43 x 32mm.5 years of warranty.Manufacturer: MEAN WELL.This source is designed to work directly with leds (plates LED or COBs), not with LED strips. Must be equipment that is fed in a steady stream.This source can operate in either Constant Current when we connect the LEDs directly to have a voltage within the Range of Output Voltage mode Constant Current and a working current equal to the output current.You can also work in voltage mode constant giving a fixed voltage of 42V if the load is powered at constant voltage and does not overcome the maximum output power.With plastic housing, designed for applications of LED lighting or LED displays. Suitable for dry environments, humid, and wet conditions. Complies with the requirements of security at the global level to iiluminación. |
| आउटपुट कनेक्टर | Cable |
| प्रविष्टि CA को प्रकार | Single-phase |
| वारेन्टी (वर्ष) | 5,00 |
| उत्पत्तिको देश | China |
| आउटपुट वर्तमान mA | 1400, 1450 |
| न्यूनतम आउटपुटको तीव्रता (mA) | 1.430,00 |
| आउटपुट अधिकतमको तीव्रता (mA) | 1.430,00 |
उत्पादन विवरण
More details
मुख्य विशेषताहरू
- औद्योगिक स्तरको गुणस्तर
- RoHS अनुरूप
- सीई प्रमाणित
- १-वर्षीय वारंटी
प्राविधिक विवरणहरू
LED driver.
उत्पादन कागजातहरू
डेटासिट
प्राविधिक विशिष्टताहरू र प्रदर्शन डेटा
प्रयोगकर्ता म्यानुअल
स्थापना र सञ्चालन मार्गनिर्देश
